NSK 50TAC100C轴承详细信息
50TAC100C轴承是NSK轴承品牌、滚珠丝杠支撑轴承的轴承型号,常用于飞机喷气式发动机、小型汽车前轮、提升机、差速器、造纸机械、汽车转向销、燃机、塑料、掘进机、厨具设备等领域。
后缀列表:【C:接触角 60°】
NSK 50TAC100C轴承详细参数
|
轴承型号: | 50TAC100C |
Recommended脂润滑Quantities(cc/轴承): | 10.2 |
接触角(°): | 60 |
重量(kg)(大约): | 0.778 |
基本尺寸(mm) |
d: | 50 |
D: | 100 |
B: | 20 |
r(min.): | 1 |
r1(min.): | 0.6 |
参考尺寸(mm) |
d1: | 67.5 |
d2: | 79 |
D1: | 79 |
D2: | 87.7 |
极限转速(min-1) |
脂润滑: | 3000 |
油润滑: | 3900 |
预紧(DB&DF)(N) |
H: | 4650 |
轴向刚度(DB&DF)(N/μm) |
H: | 1410 |
Starting torque(2)(DB and DF)(N・m)(大约) |
H: | 0.42 |
Basic Dynamic Load Rating Ca(Classification by Fa Load Row Number) |
Single Row Load(kN): | 66 |
Double Row Load(kN): | 107 |
Triple Row Load(kN): | 142 |
Limiting 轴向 load(1)(Classification by Fa Load Row Number) |
Single Row Load(kN): | 104 |
Double Row Load(kN): | 208 |
Triple Row Load(kN): | 310 |
其他参数(详情请电话咨询) |
HPS: | HPS |
LangID: | 1 |
hidYobi: | 50TAC100C |
